HyPanel Lite

Basic Information

  • Model Number
  • Power Supply
  • Operation System
  • DDR/Flash
  • Wi-Fi
  • Bluetooth
  • Ethernet ports
  • ZigBee
  • Output
  • Microphone
  • Speaker
  • KS41-R2-EU
  • 180~260VAC,50HZ
  • Linux
  • 128MB/ 256MB
  • IEEE802.11 b/g/n, @2.4GHz
  • Bluetooth 4.2
  • 1xRJ45, 10/100Mbps adaptive
  • ZigBee 3.0
  • 2-gang,1200W total;
  • 800W/gang for resistive;
  • 400W/gang for LED/CFL
  • Dual microphone,-26DBFS
  • Single speakers, 8Ω / 1.5W

Appearance

  • Material
  • Screen
  • Screen Resolution
  • Screen Brightness
  • Metal buttons, V0 fireproof PC
  • 3.27” touch screen
  • 320x480 pixels
  • 220 cd/㎡

Sensors Built In

  • Proximity sensor
  • Light Sensor
  • Temperature Sensor
  • Humidity Sensor
  • 30~60cm
  • Low-level lux detection
  • ±1℃,range: -10℃~55℃
  • ±5%, range: 10%~90%RH, without condensation

Working Environment

  • Environment
  • Working Humidity
  • Working Temperature
  • Storage Temperature
  • For indoor use only
  • 10%~90%RH,without condensation
  • -10°C ~ +55°C
  • -20°C ~ +65°C

Installation

  • Installation
  • Flush Mounted Box Standard
  • Wiring Way
  • Wall flush mounting
  • EU/UK/GB standard
  • L- + N- wire required

Application Scenario

  • Villas
  • Apartment complexes
  • Home automation systems
  • Modern interiors
  • Yes
  • Yes
  • Yes
  • Yes
